FZR750RR
- OW01
Manufacturer's
specifiction |
Engine |
| Configuration |
Liquid cooled, four stroke, transverse four cylinder,
DOHC, 5 valves per cylinder. |
Lubrication |
|
| Bore & Stroke |
72 x 46 mm |
Ignition |
Transistor controlled digital |
| Capacity |
749.00 ccm (45.70 cubic inches) |
Charging System |
|
| Compression Ratio |
11.2:1 |
Starter |
Electric |
| Maximum Power |
121 hp 88.3 KW @ 12000- (rear tyre 108.8 hp @ 12500
rpm ) |
Transmission |
|
| Maximum Torque |
7.2 kg-m @ 9000 rpm |
Gearbox |
6 speed / chain |
| Fuel |
4X BDST38mm Mikuni carbs |
Clutch |
Multi-plate wet clutch |
| Exhaust |
Alloy muffler |
|
|
| Chassis |
| Frame |
Deltabox alloy beam frame |
|
|
| Dimensions |
187.0 kg (dry)
1,445 mm
seat height 780 mm
|
Tyres |
130/60 ZR17
180/55 ZR17 |
| Front Suspension |
43mm Telescopic preload forks, compression and rebound
damping adjustment |
Brakes |
2x 320mm discs 4 piston calipers
Single 210mm disc 2 piston caliper |
| Rear Suspension |
Öhlins Monocross preload compression and rebound
damping adjustment, |
Fuel Capacity |
23 Litres |
|
|
 |
| |
